Home > Electrical Equipment > DC-DC Converters > 12V to 24V DC-DC Boost Converters

1/1

12V to 24V DC-DC Boost Converters, 1A-50A, 24W-1200W

High-efficiency 12V to 24V DC-DC boost converter.
IP68 waterproof, multiple protections, wide current range 1A–50A.
Ideal for automotive, marine, industrial, LED and solar power systems.

$48.77

SAVE $10.00 WITH PURCHASE OVER 1 UNITS

Get it

AUTO10

Received successfully

Coupon Code

Please select the information you want X

Input & Output Voltage:

12V to 24V
Output Current & Power:

1A 48W

3A 72W

5A 120W

10A 240W

15A 360W

20A 480W

25A 600W

30A 720W

40A 960W

50A 1200W

Quantity:

1/1

Overview
Dimension
FAQ

OVERVIEW
GoodProx 12V to 24V DC-DC boost converter provides stable, efficient voltage step-up from 12V to 24V for vehicle, marine, industrial and solar applications. Supporting 1A–50A / 24W–1200W, this IP68 boost converter features ultra-high conversion efficiency, full protections and a rugged waterproof design. It is the reliable 12V to 24V step-up converter for mobile and industrial power systems.

FEATURES

Wide Power Range: 1A–50A, 24W–1200W for multiple load demands.
High Efficiency: Up to 95% conversion, low power loss.
IP68 Waterproof: Dustproof, waterproof, suitable for harsh environments.
Full Protections: Over-voltage, over-current, over-temperature protection.
Stable Output: Voltage regulation ±1%, low ripple & noise.
Wide Temp Range: -40°C to +85°C working temperature.
Compact & Rugged: Solid structure for vehicle & industrial use.
Certified Safe: CE, RoHS certified, 18-month warranty.

SPECIFICATION GP-CVT-12S24, 12V to 24V Series

SKU/Model	GP-12S2401	GP-12S2403	GP-12S2405	GP-12S2410	GP-12S2415	GP-12S2420	GP-12S2425	GP-12S2430	GP-12S2440	GP-12S2450
Rated Voltage	12V DC
Rated Voltage Range	10-16V DC	10-23V DC	10-23V DC	10-23V DC	10-23V DC	10-23V DC	10-16V DC	10-16V DC	10-16V DC	10-16V DC
Output Voltage	24V DC
Voltage Regulation	±1%
Output Current	1A	3A	5A	10A	15A	20A	25A	30A	40A	50A
Output Power	24W	72W	120W	240W	360W	480W	600W	720W	960W	1200W
Output Type	Single Phase
Efficiency	95%	95%	95%	92%	92%	94%	95%	95%	94%	93%
Load Regulation	<2%
No Load Loss	28mA	51mA	20mA	30mA	50mA	60mA	70mA	70mA	70mA	70mA
Ripple & Noise	200mVp-p	260mVp-p	220mVp-p	160mVp-p	200mVp-p	180mVp-p	240mVp-p	240mVp-p	240mVp-p	300mVp-p
Protections	Over load, Over Voltage and Over temperature protections
Waterproof Level	IP68
Certificates	CE, RoHS
Working Temp.	-40 ~ + 85℃
Weight (kg)	0.10	0.12	0.12	0.33	0.33	0.55	1.6kg	1.6kg	2.3kg	3.1kg
Size (mm)	645722	645722	645722	747432	747432	1008039	5.9112763	5.9112763	22012763	30012763
Warranty	18 months

APPLICATIONS

✔️Industrial

✔️Alternative Energy

✔️Golf Cart

✔️Forklift

✔️Electromotor

✔️Telecommunications

✔️Boat & Yacht

✔️Medical

✔️Dua Battery System

✔️LED Marketplaces and so on.

USAGE NOTE

1. Use within rated input voltage range for 12V to 24V step-up converter.
2. Do not overload the output current or power.
3. Ensure good heat dissipation for high-power models.
4. Follow wiring diagram to avoid short circuit.
5. Keep away from flammable materials during operation.

Why Choose GoodProx GP-CVT-12S24 Boost Converter?

✅ Stable 24V output from 12V input for 12V to 24V DC-DC boost converter.
✅ IP68 waterproof design for outdoor & harsh environment use.
✅ Up to 95% high efficiency saves energy & reduces heat.
✅ Full protections ensure safe long-term operation.
✅ Wide current selection from 1A to 50A fits all needs.
✅ CE & RoHS certified, 18-month warranty for reliability.

GP-12S2401 / GP-12S2403 / GP-12S2405
Size: 64*57*22mm

GP-12S2410 / GP-12S2415
Size: 74*74*32mm

GP-12S2420
Size: 100*80*39mm

DC-DC Converter FAQ

What is the difference between a Buck and a Boost converter? +

A Buck converter (Step-down) reduces the input voltage to a lower output voltage.
A Boost converter (Step-up) increases the input voltage to a higher output voltage.

What does "Isolated" vs "Non-Isolated" mean? +

Isolated converters have electrical separation (via a transformer) between input and output, which provides safety and noise immunity.
Non-Isolated converters share a common ground and are typically more efficient and compact.

What is the efficiency of this converter? +

Efficiency is the ratio of output power to input power. High-efficiency converters (e.g., >95%) minimize power loss as heat, which is crucial for battery-powered applications and thermal management.

Why is my converter overheating? +

Possible causes:

Exceeding the rated output load → Reduce power draw.
Poor ventilation → Ensure airflow around the unit.
Faulty wiring → Check connections.

The output voltage is unstable. What should I do? +

Try:

Check input voltage (must be in input voltage range).
Verify load is within output limit.
Test with a multimeter to confirm output.

Can I use this with solar panels? +

Yes, DC-DC converters are commonly used in solar systems to match the panel voltage to the battery or load voltage. Ensure the input voltage range covers your solar panel's maximum power point (MPP).
