48V to 24V DC-DC Buck Converters, 3A~60A, 72W~1500W

Name: 48V to 24V DC-DC Buck Converters, 3A~60A, 72W~1500W
Brand: GoodProx - Industrial Automation Products Online Store & Solution
SKU: GP-CVT-48S24
Price: 69.69 USD
Availability: InStock
Rating: 5 (1 reviews)

Ultra-Wide input range 32-60V to 24V buck converter.
IP68 waterproof, up to 98% efficiency, full protections, 3A–60A.
Ideal for vehicle, marine, industrial, solar and LED power systems.
Simple design, clear interface, easy to install and integrate quickly.

$69.69

SAVE $10.00 WITH PURCHASE OVER 1 UNITS

Get it

AUTO10

Received successfully

Coupon Code

CONTINUE SHOPPING

Please select the information you want X

Input & Output Voltage:

48V to 24V
Output Current & Power:

3A 72W

5A 120W

10A 240W

20A 480W

30A 720W

40A 960W

50A 1200W

60A 1500W

Quantity:

1/1

Overview
FAQ

OVERVIEW
GoodProx 48V to 24V DC-DC buck converter provides stable voltage step-down from 48V to 24V for automotive, marine, industrial and solar applications. Covering 3A–60A / 72W–1500W, this IP68 buck converter features up to 98% efficiency, full protections and a rugged sealed design. It is the reliable 48V to 24V step-down converter for mobile and industrial power systems.

FEATURES

Wide Power Range: 3A–60A, 72W–1500W for versatile load demands.
High Efficiency: Up to 98% conversion, low energy loss.
IP68 Waterproof: Dustproof, waterproof, shock-resistant for harsh environments.
Full Protections: Over-voltage, over-current, over-temperature, short-circuit protection.
Stable Output: Voltage regulation ±1%, low ripple & noise.
Wide Temp Range: -40°C to +85°C working temperature.
Cast Aluminum Shell: Rugged, durable, excellent heat dissipation.
Certified Safe: CE, RoHS certified, long warranty.

SPECIFICATION GP-CVT-48S24, 48V to 24V Series

SKU/Model	GP-48S2403	GP-48S2405	GP-48S2410	GP-48S2420	GP-48S2430	GP-48S2440	GP-48S2450	GP-48S2450
Rated Voltage	48V DC
Rated Voltage Range	30-60V DC	32-60V DC	32-60V DC	35-60V DC	35-60V DC	35-60V DC	35-60V DC	35-60V DC
Output Voltage	24V DC
Voltage Regulation	±1%
Output Current	3A	5A	10A	20A	30A	40A	50A	60A
Output Power	72W	120W	240W	480W	720W	960W	1200W	1500W
Output Type	Single Phase
Efficiency	96%	96%	98%	95%	95%	95%	96%	96%
Load Regulation	<2%
No Load Loss	50mA	40mA	2mA	30mA	70mA	70mA	70mA	70mA
Ripple & Noise	180mVp-p	50mVp-p	100mVp-p	96mVp-p	240mVp-p	350mVp-p	180mVp-p	180mVp-p
Protections	Over load, Over Voltage and Over temperature protections
Waterproof Level	IP68
Certificates	CE, RoHS
Working Temp.	-40 ~ + 85℃
Weight (kg)	0.12	0.30	0.30	0.30	0.55	1.6	2.35	2.35
Size (mm)	645722	747432	747432	747432	1008039	15012763	22012763	22012763
Warranty	18 months

APPLICATIONS

✔️Industrial

✔️Alternative Energy

✔️Golf Cart

✔️Forklift

✔️Electromotor

✔️Telecommunications

✔️Boat & Yacht

✔️Medical

✔️Dua Battery System

✔️LED Marketplaces and so on.

USAGE NOTES

1. Use within rated input voltage range for 48V to 24V step-down converter.
2. Do not overload the output current or power.
3. Ensure good heat dissipation for high-power models.
4. Follow wiring diagram to avoid short circuit.
5. Keep away from flammable materials during operation.

Why Choose GoodProx GP-CVT-48S24 Buck Converter?

Stable 24V output from 48V input for 48V to 24V DC-DC buck converter.
IP68 waterproof design for outdoor & harsh environment use.
Up to 98% high efficiency saves energy & reduces heat.
Full protections ensure safe long-term operation.
Wide current selection from 3A to 60A fits all needs.
CE & RoHS certified for industrial & vehicle safety.

DC-DC Converter FAQ

What is the difference between a Buck and a Boost converter? +

A Buck converter (Step-down) reduces the input voltage to a lower output voltage.
A Boost converter (Step-up) increases the input voltage to a higher output voltage.

What does "Isolated" vs "Non-Isolated" mean? +

Isolated converters have electrical separation (via a transformer) between input and output, which provides safety and noise immunity.
Non-Isolated converters share a common ground and are typically more efficient and compact.

What is the efficiency of this converter? +

Efficiency is the ratio of output power to input power. High-efficiency converters (e.g., >95%) minimize power loss as heat, which is crucial for battery-powered applications and thermal management.

Why is my converter overheating? +

Possible causes:

Exceeding the rated output load → Reduce power draw.
Poor ventilation → Ensure airflow around the unit.
Faulty wiring → Check connections.

The output voltage is unstable. What should I do? +

Try:

Check input voltage (must be in input voltage range).
Verify load is within output limit.
Test with a multimeter to confirm output.

Can I use this with solar panels? +

Yes, DC-DC converters are commonly used in solar systems to match the panel voltage to the battery or load voltage. Ensure the input voltage range covers your solar panel's maximum power point (MPP).
